XLD-300A

  • Parameters
  • Test Video
  • Operation Video
  • Characteristic
  • Download
  • Strength
Detectable Explosives:

TNT, RDX, PETN, Nitroglycerin, Black Powder, DNT, Tetryl, HMX, EGDN, entropy‑based explosive,

TATP, HMTD, C4, Semtex and other military, civil and homemade explosives. New samples can be added as required.

Detectable Narcotics:

Cocaine, Heroin, Cannabis, Methamphetamine, Ketamine, Morphine, Ecstasy, Mephedrone,

Pethidine, Methcathinone, Blue Smurfs and other common narcotics on the market. New samples can be added as required.

Sensitivity: Picogram and nanogram levelsAnalysis Time: 8 s in standard mode, 2 s in rapid modeWarm‑up Time: ＜12 minFalse‑alarm Rate: ≤1%Detection Rate: ≥99%Weight: ＜3.5 kgDimensions: 292 mm (W) × 171 mm (L) × 136 mm (H)Battery: Operating time ＞2 hours, standby time ＞12 hoursPower Supply: AC 110 V/220 V, 50‑60 Hz, output 19.5 VOperating/Storage Temperature: -20℃ ~ 60℃Operating/Storage Humidity: ＜95%Operating Air Pressure: 60 kPa‑106 kPa

Carton Size：116*25*32CM  14KG/1pc

Product Advantages of Portable Explosives and Narcotics Detector


  1. Ultra‑fast Analysis
    It features rapid detection and analysis, with results available within 3 seconds.

  2. Accurate Detection
    Adopting ion mobility spectrometry technology, it can accurately identify the composition and type of hazardous materials, and report the exact name of detected dangerous goods with high precision.

  3. Automated & Real‑time Service
    It supports automatic calibration, automatic cleaning and automatic diagnosis, as well as real‑time printing, real‑time database software update and real‑time data storage.

  4. Trace Detection
    In practical operation, there is no need to aim at hazardous materials inside packages. Simply wipe the package surface with a test swab to detect dangerous goods, enabling easy operation.

  5. Dual‑mode Simultaneous Detection
    It performs simultaneous dual‑mode detection for both explosives and narcotics without mode switching. A single device can detect and alarm for both substances at the same time.

  6. Multiple Alarm Modes
    It provides multi‑form alarm prompts including sound, light, color and text. Panic‑free alarm modes can be customized as required by users.

  7. Multi‑language Support
    It supports multiple languages including Chinese, English and Portuguese, with customized language versions available upon request.

  8. Hierarchical Permission Management
    It features hierarchical permission management for operators, administrators, maintenance personnel and R&D staff, ensuring high‑safety device operation.

  9. Full‑color Screen
    Equipped with a 5.6‑inch LED color LCD screen, it clearly displays spectrograms as well as names of detected explosives and narcotics.

  10. Ultra‑long Standby Time
    Built‑in rechargeable lithium battery provides continuous working time of no less than 2 hours and standby time up to 12 hours.

  11. Powerful Substance Database
    The database contains nearly 100 common types of narcotics and explosives, and supports real‑time update and expansion per customer requirements.

  12. Handheld Operation
    Compact size and lightweight design ensure easy portability for multiple application scenarios.

  13. Multi‑layer Protection
    With drop‑proof design, it is resistant to impact, vibration, sand‑dust and electromagnetic interference, adapting to complex working environments.

  14. Low‑cost Consumables
    It uses molecular sieve desiccant with low cost and easy replacement.
