Penetration: 30 mm steel plate   Single‑shot X‑ray Radiation Dose: 1 mSv/h

Film Safety: Compatible with high‑speed film (ASA/ISO 1600 sensitivity)

Safety & Environmental Parameters

Operating Temperature: 0 °C to 45 °C   Storage Temperature: −40 °C to 70 °C

Relative Humidity: 20%–95% (non‑condensing)

Cooling Method / Duty Cycle: Sealed oil‑cooled / 100% continuous operation

X‑ray Sensor: Multi‑energy L‑shaped photodiode array detector

Image Gray Scale: 4096 levels (12‑bit)   Equipment Grounding: Equipped with reliable grounding terminal

Main Unit Noise: 62 dB (A‑weighted)

Image Display Functions

Color/black‑and‑white display, pseudo‑coloring, edge enhancement, image enhancement, high‑penetration mode,

image playback (20 images), alarm function, organic material removal, inorganic material removal, image inversion,

saturation scanning, image saving, image retrieval, additional image display frame

Image Scanning & Magnification

Image Scanning: Brightness adjustment for B&W scanning, saturation scanning for color images, image masking

Image Magnification: 1‑9 selectable zones, supporting 2×, 4×, 8×, 16× magnification

Image Storage: Real‑time storage of 1 image with image transmission function

Other Functions

Date & time display, operator ID, equipment ID, automatic image insertion, working status

display, thumbnail display, operator identification code, B&W/color switching, baggage counting

and reset, emergency stop & power‑on self‑test, X‑ray direction switching, network interface,

system operation & X‑ray emission timing, automatic maintenance reminder

Display

1 × 17‑inch flat‑screen color monitor, resolution 1280×1024, dot pitch <0.28 mm, field

frequency ≥75 Hz (max 100 Hz), flicker‑free, 24‑level gray scale, compliant with MPRII

and TCO95 standards, with automatic protective screen.

Penetration inspection available regardless of object placement, with no blind spots or dead zones.

Equipment housing adopts lead‑shielded panels; inlet and outlet are fitted with lead shielding curtains.

X‑ray indicator lights and emergency stop buttons are installed at inlet and outlet.
