Functional Features of 5030C Tunnel‑Type X‑ray Inspection Machine  Model: Professional Version 5030C

Basic Parameters Conveyor Load‑bearing Capacity: 150 kg Conveyor Speed: 0.2 m/s

Penetration Capacity: 30 mm steel plate

X‑ray Source    Tube Voltage: 140 kV     X‑ray Emission Direction: Bottom‑to‑top

Imaging System   X‑ray Sensor:  Multi‑energy Type

Display Screen: 19‑inch LCD (touch screen optional)

Real‑time Image Storage: Over 100 images storable   Rated Power: 1.0 kVA

Product Structure Integrated Structure

Other Configurations

Operation Console: Optional    Unpowered Luggage Rack: Included

After‑sales Service / Free Warranty: 12 months
