Penetration: Typical 40 mm steel, guaranteed 38 mm steel

Wire Resolution: Typical AWG40, guaranteed AWG38

X‑ray Generator: 2 × 160 kV, oil‑cooled; one bottom‑to‑top, one left‑to‑right

Image Enhancement: Continuous magnification from 1× to 64×, color/BW, negative

film, high/low penetration, organic/inorganic, stripe filtering, general enhancement and pseudo‑coloring, etc.

Image Archiving: Up to 50,000 images can be automatically stored, exported to USB flash drives,

and converted into six formats: JPG, BMP, XF, PNG, TIFF and GIF.

Other Functions: Time/date display, counter, user management, system startup/X‑ray activation timer,

power‑on self‑test, built‑in diagnostic tools, bidirectional scanning, system log, system standby mode, simulation training, ADS, etc.

Product Highlights

* Threat alert and material classification * Network‑ready * Energy‑saving design * International standard

configuration: Hamamatsu detectors (Japan) and Sens technology boards (UK) * One‑key shutdown

* Drug and explosive inspection * Date and time indication * Multi‑language operation

* Automatic built‑in test and self‑diagnosis * Security access key * Continuous operation for more than 1 hour
