XLD-G1


  • Parameters
  • Test Video
  • Operation Video
  • Characteristic
  • Download
  • Strength

 Power Consumption: < 3 5W

Working temperature: -25℃~55℃

Working humidity: 95%, non-condensing

External power supply: 187V~242V, 50/60HZ

Shipping weight: about 70 kg

  Product size: 2200*700*500mm


Utilizing advanced electromagnetic compatibility design, this product boasts high sensitivity and strong anti-interference capabilities,


making it suitable for security checks of dangerous items such as controlled knives and firearms.


Product Advantages


Ultra-low detection height: An alarm will sound when a metal object more than 2 cm above the ground enters the detection area.


Multi-location alarm function: When multiple metal objects from different positions on a person pass through the security gate,


an alarm will sound simultaneously, and the location of each metal object can be indicated.


Multi-zone independent detection: 33 independent detection zones, each with 256 levels of adjustable sensitivity.


Modular component design: Facilitates transportation and maintenance.


Alarm modes: 0-M1-M2
