Boot self-check function

(1) After booting, the system will automatically diagnose toconfirm ifthe equipment running condition is normal or not.

(2) System failure content will automatically display ifthere is a breakdown.

Detection area

There are no blind spots in all directions in the channel

Display LCD

Super bright 10 - inch color large LCD touch screen

Detection mode 2 modes

Mobile phone mode and metal mode

Calendar

Display ofyear, month, day, minute.

Mobile mode

Detecting mobile phones and other electronic products hidden on personnel

Metal pattern

Detection personnel concealed metals exceeding the limit

Power input

AC 100～240V, 50/60Hz

Power

≦ 20w

Working frequency

7～10 KHz

Working environment

- 20ºC～50ºC

Relative humidity

0～95%

Appearance size

2230mm (height) x 820mm (width) x 600mm (depth)

Channel size

1995mm (height) x720mm (width) x600mm (depth)

Product weight Net weight

61 kg

Appearance

The appearance is made of waterproof high-strength synthetic material, and the bottom is equipped with fixings, which is waterproof, moisture-proof and shock-proof.
