XLD-Ha (Optional Network Connection)

  • Parameters
  • Test Video
  • Operation Video
  • Characteristic
  • Download
  • Strength

Product Parameters:


Power: <30 watts


Frequency: 4-8kHz


Alarm Volume: 0-255


Alarm Time: 1-25 seconds


Alarm Sounds: 10 sounds


Power Supply: 100-220V AC


Panel Material: Waterproof ABS


Sensitivity: Adjustable range 0 to 255


Complies with GB15210-94 standard


Operating Environment: -20℃ to +45℃


Gross Weight: Approx. 24 kg


Dimensions: 2020mm (H) x 39mm (W) x 160mm (D)




5 test zones (optional network function, dry contact linkage function)


IP65 protection rating standard. Radar sensor, mechanical anti-interference.


Product Craftsmanship: Made of robust ABS material, waterproof and lightweight.


Infrared Technology: Detects interference in mechanical processes through a radar sensor.


Adjustable Sensitivity: Sensitivity can be adjusted between 0-255. The actual sensitivity can be


 disassembled according to user needs and can be carried via jewelry, belt buckles, metal zippers, etc.


Statistical Function: Intelligent statistics based on the number of people and alarm time.
